Six-Port Two-Wire Distributor, Power Adaptor Included

The DS-KAD706-P is Hikvision's Gen2 two-wire distributor supplied with an Australian power adaptor. Six cascade ports carry power out to the connected devices, and two further cascade ports let distributors be chained — which is how a two-wire system grows past a single floor or a single entrance.

Key Details

• Six ports with device power — Six two-wire cascade ports that also power the devices on them, so monitors and stations need no local power supply at each position.
• Cascades for larger systems — Two cascade ports for linking to further DS-KAD706 or DS-KAD706-S units, so an apartment block can be built up distributor by distributor.
• Power adaptor supplied — The Australian adaptor is in the box. Distributors are frequently sold bare, and discovering that on site costs a day.
• Clear diagnostics — Eight interface indicators and a reset button, so a faulty leg can be identified at the distributor rather than by walking the building.
• Bridges to the network — An RJ45 port connects the two-wire segment to the IP network for app access and remote configuration.

Where It Fits

The backbone component for any Hikvision Gen2 two-wire installation beyond a single kit — apartment blocks, multi-storey homes, and any building where several indoor stations hang off one door station.

Specifications

Assurance

• 3-Year Australian Warranty
• Genuine Hikvision stock, supplied and supported locally
• Australian-based technical support before and after purchase
