Dahua DH-PFA7711 — G1½" Camera Mount Adapter

The PFA7711 is the small aluminium adapter that lets Dahua camera hardware meet a G1½" pipe thread — the size used on pendant drops, pole arms and heavier mounting assemblies. It is a machined part rather than a pressing, Φ53 mm across and 47.8 mm tall, weighing only 0.14 kg. It is finished in white to match Dahua's standard camera and bracket colour, and rated from −40 °C to +60 °C at under 90% humidity, so it can live outdoors permanently rather than being a temporary fix.

Key Details

• G1½" pipe thread — Machined to the G1½" standard so it mates with pendant pipe and heavier mount hardware without shims or improvised adaptor plates.
• Machined aluminium — Solid aluminium in a Φ53 × 47.8 mm body — small enough to disappear behind the camera, strong enough not to be the weak link.
• Rated for outdoor life — −40 °C to +60 °C and under 90% humidity, so it holds up through Australian summers and coastal damp without seizing or corroding.
• Matched white finish — Comes in Dahua white, the same colour as the camera and bracket range, so the join does not stand out on the building.

Where It Fits

The part to add when your mount and camera hardware do not share a thread — pendant drops, pole arms and anything built around G1½" pipe. Supplied on its own, one adapter per pack, at 0.14 kg.

Specifications

Assurance

• 3-Year Australian Warranty
• Genuine Dahua stock, supplied and supported locally
• Australian-based technical support before and after purchase
