Eight Relays and Eight Supervised Inputs on the Network

The AXIS A9188 puts eight Form C relays and eight configurable I/O channels onto the network, so events anywhere in a system can drive real-world outputs. Its supervised inputs are the notable capability: they detect a cut or shorted cable rather than simply reading open or closed, which is what an input protecting something valuable has to do.

Key Details

• Supervised inputs — Four-state supervision across 0–12V distinguishes a genuine open circuit from a cut or shorted cable — a plain input reads a snipped wire as 'all clear'.
• Eight Form C relays — NO/NC contacts rated to 1A at 48V DC, for driving locks, barriers, sirens, lighting and gates.
• Network controlled — Events from cameras, analytics or access control trigger physical outputs anywhere the network reaches, without dedicated control cabling.
• Dedicated tamper input — A separate input for external tamper contacts on the enclosure or the devices it serves.
• Properly secured — Password protection, IP filtering, HTTPS and IEEE 802.1X, over IPv4 and IPv6 — appropriate for a device that can physically open doors.

Where It Fits

For integrating a security system with the physical world: camera analytics triggering a gate, an alarm driving lighting, access events switching plant. The supervised inputs make it suitable for high-security applications where cable integrity has to be monitored.

I/O INTERFACE

Digital I/O	8x I/O, configurable as input, supervised input with analog read-out, or output
Digital input range	0 to max 40 V DC; supervision between 0–12 V (4 states)
Digital output	0 to max 40 V DC, open drain, max 100 mA
Relays	8x Form C relays, NO/NC contacts, max 1 A, 48 V DC (max 30 V DC outdoors)
Tamper	Dedicated tamper input for external tamper contact(s)

NETWORK & SECURITY

Network port	1x RJ45 10BASE-T/100BASE-TX
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X, digest authentication
Protocols	IPv4, IPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS

SYSTEM INTEGRATION

API	Open API for software integration, including VAPIX
Hosting	AXIS Video Hosting System (AVHS) with One-Click Connection
Edge applications	Support for AXIS Camera Application Platform (ACAP)
Event history	30,000 events, First In First Out (FIFO)
Event actions	Notification via email, HTTP, HTTPS and TCP; external output port; status LED
Event triggers	Tamper detection, network lost, configuration, event logger, hardware, input signal, schedule, system, time, supervised inputs (4 states), relays and outputs, heartbeat lost

POWER

Power in	8–28 V DC, max 26 W, or PoE IEEE 802.3af Type 1 Class 3 / IEEE 802.3at Type 2 Class 4
Power out	12 V DC and 24 V DC
Max power out	Shared between 12 V and 24 V outputs — PoE Class 3: 3.6 W; PoE Class 4 or DC input: 12 W
Connectors	Terminal blocks: 1x DC IN, 2x DC out, 8x inputs/outputs, 8x relays, 1x tamper, 1x RS485 (for future use)
Cable size	CSA: AWG 28–16; CUL/UL: AWG 30–14

GENERAL & ENVIRONMENTAL

Memory	256 MB RAM, 256 MB Flash
Operating conditions	-30 °C to 55 °C (-22 °F to 131 °F)
Humidity	20–85% RH (non-condensing)
Dimensions	43 x 186 x 120 mm (1.7 x 7.3 x 4.7 in)
Weight	500 g (1.1 lb)
Sustainability	PVC free
Approvals	EN 55022 Class B, EN 50130-4, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, C-tick AS/NZS CISPR22 Class B, VCCI Class B, IEC/EN/UL 62368-1, EN 50581
Included accessories	Connector kit, jumper kit, TORX Key TR20, installation guide
Optional accessories	AXIS T8133 Midspan 30 W, AXIS T8129 PoE Extender, AXIS T8007 PS24 power supply, AXIS T98A15-VE Surveillance Cabinet
Part number	0820-001
Warranty	3-Year Australian Warranty
