Two 6MP TiOC 3.0 Turrets and Four 6MP Dual-Light Turrets

The 6MP version of the mixed six-camera system, and the sweet spot for most homes. Two TiOC 3.0 turrets bring the siren, strobe and talk-back to the front of the property; four Smart Dual-Light turrets hold the remaining angles in 24/7 colour. The eight-channel recorder powers all six and keeps two channels in reserve.

What’s in the Kit

2 × TiOC cameras	DH-IPC-HDW3649H-AS-PV-ANZ-S2 — 6MP TiOC 3.0 active-deterrence turret: siren, red/blue strobe, two-way audio, IR 30 m plus warm light 30 m, SMD 4.0, IP67
4 × Dual-Light cameras	DH-IPC-HDW3667EM-S-IL-ANZ — 6MP Smart Dual-Light turret, fixed 2.8 mm F1.4, IR 30 m plus warm light 30 m, 120 dB WDR, built-in microphone, SMD 4.0, IP67
1 × Recorder	DHI-NVR4108HS-8P-AI/ANZ — 8-channel 4K WizSense AI recorder, 8 built-in PoE ports, one SATA bay, 4K HDMI, DMSS remote access
Hard drive	Not included — one SATA bay takes a drive up to 10 TB, take a surveillance-grade drive sized to the retention you need
Power	All six cameras run from the recorder's PoE ports; two ports stay free
Mounting	Every camera ships with its eave/soffit bracket, drill template and fixings
Cabling	Cat6 is run on site and is not supplied; pre-made patch leads are available separately

What Makes This Kit

• Active deterrence at the front — siren, red-and-blue strobe and two-way audio on the two cameras that see people arrive
• 6MP across the board — more detail than 5MP, materially less storage than 4K — the balance point for a six-camera system
• F1.4 optics on the Dual-Light turrets — a fast lens is what makes low-light colour work, not just the LED beside it
• 120 dB WDR — for cameras looking from shade into sun, which is most Australian frontages
• Two channels spare — room to add a shed or gate camera to the same recorder

Where It Fits

A strong all-round choice for a family home — deterrence at the entry, full-colour coverage everywhere else, and headroom to grow.

TiOC 3.0 Camera — DH-IPC-HDW3649H-AS-PV-ANZ-S2 (×2)

Camera Type	6MP TiOC 3.0 Active-Deterrence Full-Colour Turret (WizSense)
Max. Resolution	6MP · 3200 × 1800 @ 25/30 fps
Lens	Fixed 2.8 mm
Night Vision	IR 30 m + Warm Light 30 m · full-colour 24/7
Active Deterrence	Siren · red/blue strobe lights · voice warning
Audio	Built-in dual mic · 1-ch speaker · two-way talk
AI	SMD 4.0 · Perimeter Protection · Tripwire
Power / Ingress	PoE 802.3af · 12 VDC · IP67
Warranty (Australia)	3-Year Australian Warranty

Smart Dual-Light Camera — DH-IPC-HDW3667EM-S-IL-ANZ (×4)

Camera Type	6MP WizSense 3 Smart Dual-Light Eyeball Turret
Max. Resolution	6MP · 3288 × 1850 @ 25/30 fps
Lens	Fixed 2.8 mm F1.4 · 110° H FOV
Night Vision	Smart Dual Light · IR 30 m + Warm Light 30 m
WDR	120 dB
AI	SMD 4.0 · AcuPick (with 5-Series NVR) · Perimeter Protection · AI SSA
Audio	Built-in microphone
Power / Ingress	PoE 802.3af · 12 VDC · 9.5 W max · IP67 · –40 °C to +60 °C
Warranty (Australia)	3-Year Australian Warranty

Recorder — DHI-NVR4108HS-8P-AI/ANZ

Model	DHI-NVR4108HS-8P-AI/ANZ
Recorder Type	8-channel 4K WizSense AI NVR
Channels	8 IP channels
PoE	8 built-in PoE ports
Storage	1 × SATA bay · HDD not included
Video Output	4K HDMI
AI Functions	WizSense · SMD 4.0 smart motion detection · Quick Pick
Remote / App	DMSS (iOS & Android) · P2P
Warranty (Australia)	3-Year Australian Warranty

Assurance

• 3-Year Australian Warranty
• Genuine Dahua stock, supplied and supported locally
• Australian-based technical support before and after purchase
