One 8MP TiOC 3.0 Turret and Three 8MP Dual-Light Turrets

Four 4K cameras with a single active-deterrence turret at the front. The TiOC 3.0 handles the approach with its siren, red-and-blue strobe and two-way audio; three Smart Dual-Light turrets record the rest of the property in full colour. Everything at 8MP, everything powered by the four-channel recorder.

What’s in the Kit

1 × TiOC camera	DH-IPC-HDW3849H-AS-PV-ANZ-S2 — 8MP TiOC 3.0 active-deterrence turret: siren, red/blue strobe, two-way audio, IR 30 m plus warm light 30 m, SMD 4.0, IP67
3 × Dual-Light cameras	DH-IPC-HDW3867EM-S-IL-ANZ — 8MP 4K Smart Dual-Light turret, fixed 2.8 mm, IR 30 m plus warm light 30 m, built-in microphone, SMD 4.0, IP67
1 × Recorder	DHI-NVR4104HS-P-AI/ANZ — 4-channel 4K WizSense AI recorder, 4 built-in PoE ports, one SATA bay, 4K HDMI, DMSS remote access
Hard drive	Not included — one SATA bay, takes a surveillance-grade drive up to 10 TB
Power	All four cameras run from the recorder's PoE ports
Mounting	Every camera ships with its eave/soffit bracket, drill template and fixings
Cabling	Cat6 is run on site and is not supplied; pre-made patch leads are available separately

What Makes This Kit

• 4K on all four — the deterrence camera and the three quiet ones record at the same 3840 × 2160 — no weak channel
• Deterrence where people arrive — one TiOC at the front is usually where the whole deterrent value of a system sits
• Full-colour nights throughout — dual illuminators on every camera, switching on detection rather than at dusk
• SMD 4.0 classification — human and vehicle filtering on the camera, before an alert reaches your phone
• Compact head end — a four-channel recorder that fits on a shelf and needs one power point

Where It Fits

For a house that wants 4K throughout and deterrence at the front door, without paying for a larger recorder it will not fill.

Cameras at a Glance

TiOC 3.0 (×1)	DH-IPC-HDW3849H-AS-PV-ANZ-S2 · 8MP 3840×2160 · IR 30 m + warm 30 m · siren + strobe + two-way talk · SMD 4.0 · IP67
Dual-Light (×3)	DH-IPC-HDW3867EM-S-IL-ANZ · 8MP 3840×2160 · IR 30 m + warm 30 m · full-colour 24/7 · built-in mic · SMD 4.0 · IP67
Warranty	3-Year Australian Warranty

TiOC Camera — DH-IPC-HDW3849H-AS-PV-ANZ-S2 · Full Specifications

SKU	DH-IPC-HDW3849H-AS-PV-ANZ-S2 (White) · DH-IPC-HDW3849H-AS-PV-ANZ-S2-BLK (Black)
Camera Type	8MP 4K TiOC 3.0 WizSense IP Network Turret · Active Deterrence
Image Sensor	1/2.7" Progressive Scan CMOS
Max Resolution	3840 × 2160 (8MP / 4K) @ 25/30 fps
Lens Type	Fixed-focal, 2.8 mm (F1.6) · M12 mount (3.6 mm option available)
Angular Field of View	H: 106° · V: 55° · D: 125° (2.8 mm)
DORI Distance (2.8 mm)	Detect 91.0 m · Observe 36.4 m · Recognise 18.2 m · Identify 9.1 m
Min. Illumination	Colour: 0.003 lux @ F1.6 · B/W: 0.0003 lux · 0 lux (IR ON)
Dynamic Range	120 dB True WDR
Day & Night	Auto (ICR) / Colour / B&W
Illuminators	1 × IR LED (30 m) · 1 × Warm-light LED (30 m) · Smart Dual-Light auto switching
Image Enhancement	3D NR · HLC · BLC · Defog · AI SSA · Smart Illumination · Image Rotation
Active Deterrence	Red/blue flashing warning lights · Built-in siren · Voice broadcast (custom audio supported)
Intelligent Video	AcuPick · SMD 4.0 · IVS (Tripwire, Intrusion · human/vehicle classification) · Quick Pick · AI SSA
Video Compression	Smart H.265+ · Smart H.264+ · H.265 · H.264 · MJPEG (sub-stream)
Streaming	Triple Streaming — Main 3840×2160 · Sub 704×576 · Third 1920×1080
Audio Compression	G.711a · G.711Mu · G.726 · G.723 · PCM (Two-Way Audio)
IP Camera Protocol	ONVIF Profile S/G/T · CGI · Milestone · P2P · RTMP
Network Protocols	IPv4/v6 · HTTP/HTTPS · TCP/UDP · RTP/RTSP/RTCP/RTMP · SMTP · FTP/SFTP · DHCP · DDNS · UPnP · NTP · ICMP · IGMP · SNMP · 802.1x
Cyber Security	Trusted boot · HTTPS · 802.1x · IP/MAC filtering · X.509 import · syslog · video/firmware/config encryption
Ethernet	RJ-45 (10/100BASE-T)
Alarm I/O	1 alarm in · 1 alarm out
Audio I/O	Dual built-in MIC · 1-channel speaker · 1 × RCA in / 1 × RCA out
Edge Storage	MicroSD up to 512 GB
Weatherproof Rating	IP67
Operating Temperature	−40 °C to +60 °C · < 95% RH
Power Source	12 V DC · PoE (IEEE 802.3af) · ±30% wide voltage
Power Consumption	Basic 3.7 W (12 V DC) / 5.3 W (PoE) · Max 7.4 W (12 V DC) / 9.5 W (PoE)
Mobile App	DMSS (iOS & Android) · Smart PSS · DSS
Approvals	CE-LVD (EN 62368-1) · CE-EMC 2014/30/EU · FCC Part 15 Subpart B · UL/CUL 62368-1
Housing	Metal · White or Black
Dimensions	110.9 mm × Φ 122.0 mm
Weight	0.745 kg (net) · 0.915 kg (gross)
Warranty	3-Year Australian Warranty

Dual-Light Cameras — DH-IPC-HDW3867EM-S-IL-ANZ (×3)

Field of View	Horizontal 110° · Vertical 58° · Diagonal 132°
Close Focus Distance	1.4 m
Detect	84.8 m
Observe	33.9 m
Recognise	17.0 m
Identify	8.5 m

Dual-Light Cameras — DH-IPC-HDW3867EM-S-IL-ANZ (×3) · Camera and Lens

Model	DH-IPC-HDW3867EM-S-IL-ANZ
Camera Type	Fixed-focal eyeball / turret network camera
Image Sensor	1/2.7-inch CMOS
Maximum Resolution	3840 × 2160 (8MP 4K)
Frame Rate	Up to 25/30 fps at 8MP
Minimum Illumination	0.007 lux colour · 0.0007 lux B/W · 0 lux with illuminator on
Lens	2.8 mm fixed-focal · M12 mount · F1.4
Field of View	H 110° · V 58° · D 132°
Angle Adjustment	Pan 0°–360° · Tilt 0°–80° · Rotation 0°–360°
WDR	120 dB
Image Features	BLC · HLC · 3D NR · defog · privacy masking · LDC

Dual-Light Cameras — DH-IPC-HDW3867EM-S-IL-ANZ (×3) · Illumination and Intelligence

IR Illumination	Up to 30 m
Warm Light	Up to 30 m
Illuminators	2 multi-core IR + warm-light LEDs
Smart Motion Detection	SMD 4.0
Perimeter Protection	Tripwire and intrusion with human/vehicle classification
AcuPick	Yes, with compatible Dahua back-end devices
AI SSA	Yes
Smart Search	Yes, with compatible Smart NVR

Dual-Light Cameras — DH-IPC-HDW3867EM-S-IL-ANZ (×3) · Video, Audio and Storage

Compression	H.265 · H.264 · Smart H.265+ · Smart H.264+ · AI H.265/H.264 · MJPEG on sub stream
Streaming	Three streams
Main Stream	3840 × 2160 at 1–25/30 fps
Built-in Microphone	Yes
Audio Compression	PCM · G.711a · G.711Mu · G.726 · G.723
Local Storage	microSD card up to 512 GB
Network Storage	FTP · SFTP · NAS

Dual-Light Cameras — DH-IPC-HDW3867EM-S-IL-ANZ (×3) · Network, Power and Construction

Network	RJ-45 10/100 Base-T
Interoperability	ONVIF Profiles S, G, T and M · CGI
Mobile Client	Dahua DMSS for iOS and Android
Power	12 VDC or PoE 802.3af
Power Consumption	Basic 3.7 W at 12 VDC / 5.3 W PoE · Maximum 7.4 W at 12 VDC / 9.5 W PoE
Operating Conditions	–40 °C to +60 °C · ≤95% RH non-condensing
Protection	IP67 metal housing
Dimensions	105.5 mm × Ø122.0 mm
Weight	0.53 kg net · 0.71 kg gross

Recorder — DHI-NVR4104HS-P-AI/ANZ

Model	DHI-NVR4104HS-P-AI/ANZ
Recorder Type	4-channel 4K WizSense AI NVR
Channels	4 IP channels
PoE	4 built-in PoE ports
Storage	1 × SATA bay · HDD not included
Video Output	4K HDMI
AI Functions	WizSense · SMD 4.0 smart motion detection · Quick Pick
Remote / App	DMSS (iOS & Android) · P2P
Warranty (Australia)	3-Year Australian Warranty

Assurance

• 3-Year Australian Warranty
• Genuine Dahua stock, supplied and supported locally
• Australian-based technical support before and after purchase
